Ubiquiti G5 Turret Ultra on professionaalne IP-kaamera, mis on ette nähtud nii sisekeskkonna kui välisruumide jälgimiseks. Kaamera pakub kõrget kvaliteeti 4 megapikselise resolutsiooniga ja täiustatud turvakaamera funktsioonidega.
See kaamera sobib ideaalselt erinevate paigalduskohade jaoks. Kompaktne torni kujuline kujundus võimaldab paigaldamist nii laes kui seinale, kasutades pikenduskabel vaid 0,3 m. Kaamera on varustatud IP66 kaitsega, mis tagab täieliku kaitse tolmu ja vee eest, tehes selle ilmastikukindlaks ja vastupidavaks välispaigaldustele.
- Resolutsioon: 4 MP, 2K HD
- Andurite tüüp: CMOS, 1/2,4 tolli optilise sensori suurusega
- Kaadrisagedus: 30 fps
- Öö- ja päevanägemine: Jah, infrapunavaatlusega kuni 30 m
- Müra vähendamine: Jah
- Ehitatud mikrofon: Jah
- Ühendus: Ethernet LAN, POE toide
- IP kaitse: IP66 (ilmastikukindel)
- Paigaldus: Sise- ja väliskasutusele
- Kaal: 330 g
Tehnilised andmed
Üldine
| Tootja |
Ubiquiti |
| Mudel |
Ubiquiti G5 Turret Ultra (UVC-G5-TURRET-ULTRA-B) |
Design
| Form factor |
Turret |
| Housing material |
Aluminium/Polycarbonate (PC) |
| IK code |
IK04 |
| International Protection (IP) code |
IP66 |
| Mounting type |
Ceiling/wall |
| Product colour |
Black |
| Protection features |
Tamper resistant/UV resistant |
| Weatherproof |
Yes |
Performance
| Built-in processor |
Yes |
| Connectivity technology |
Wired |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Placement supported |
Indoor & outdoor |
| Processor model |
ARM Cortex-A7 |
| Type |
IP security camera |
Camera
| Lens viewing angle, diagonal |
120.6° ° |
| Lens viewing angle, horizontal |
102.4° ° |
| Lens viewing angle, vertical |
54.9° ° |
Image sensor
| Number of sensors |
1 |
| Optical sensor size |
25.4 / 2.4 mm (1 / 2.4″) " |
| Sensor type |
CMOS |
Lens system
Night vision
| LED type |
IR |
| Night vision |
Yes |
| Night vision distance |
30 m m |
Video
| Frame rate |
30 fps fps |
| Image quality adjustment |
Brightness/Colour depth/Contrast/DNR/Sharpness |
| Maximum resolution |
2688 x 1512 pixels pixels |
| Noise reduction |
Yes |
| Noise reduction technology |
2D noise reduction, 3D noise reduction |
| Privacy masking |
Yes |
| Text caption overlay |
Yes |
| Total megapixels |
4 MP MP |
| Video formats supported |
H.264 |
Audio
Network
| Bluetooth |
No |
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
Storage
Ports & interfaces
| Ethernet LAN (RJ-45) ports |
1 |
Management features
Power
| AC input voltage |
37 – 57 V V |
| Power consumption (typical) |
4 W W |
| Power source type |
PoE |
Operational conditions
| Operating relative humidity (H-H) |
0 – 90% % |
| Operating temperature (T-T) |
-30 – 50 °C °C |
Weight & dimensions
| Cable length |
0.3 m m |
| Diameter |
9 cm mm |
| Height |
71.2 mm mm |
| Weight |
330 g g |
