Ubiquiti USW-PRO-HD-24-POE on kõrgtasemel hallatav võrgulüliti, mis on spetsiaalselt kavandatud suurte ettevõtete ja andmekeskuste jaoks. Seade toetab L2/L3 funktsioonidele ja pakub professionaalset jõudlust ning usaldusväärsust kriitiliste võrgurakenduste jaoks.
See võrgulüliti on ideaalne lahendus kõrge PoE võimsusega seadmete juhtimisel, nagu juhtmevabad pääsupunktid, IP-kaamerad ja muud alimenteeritud seadmed. Kompaktne 1U formaadis kujundus võimaldab lihtsat paigaldamist standardsetesse riiulidesse.
- Pordid: 24x 2,5G Ethernet PoE++ porti + 4x SFP+ moodulipesa
- PoE võimsus: 600 W kogu eelarve, 15,4 W pordi kohta
- Jõudlus: 230 Gbit/s lülitusmahtuvus, 171 Mpps edastuskiirus
- Funktsioonid: QoS tugi, pordi peegeldamine, stapeldamine
- Toiteallikas: AC/DC, kaasas olev toiteplokk
- Mõõtmed: 442,4 x 400 x 44 mm, kaal 6,2 kg
- Värvus: Hall, riiuli kinnituse võimalus
Tehnilised andmed
Üldine
| Tootja |
Ubiquiti |
| Mudel |
USW-PRO-HD-24-POE |
Management features
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2/L3 |
| Switch type |
Managed |
Ports & interfaces
| 10G Ethernet (copper) ports quantity |
2 |
| 2.5G Ethernet (copper) ports quantity |
22 |
| Basic switching RJ-45 Ethernet ports quantity |
22 |
| Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
| Power connector |
AC/DC |
| SFP+ module slots quantity |
4 |
Network
| 10G support |
Yes |
| Broadcast storm control |
Yes |
| Flow control support |
Yes |
| IPv4 routes |
12000 |
| Networking standards |
IEEE 802.1x |
| Number of VLANs |
1000 |
| Port mirroring |
Yes |
| Rate limiting |
Yes |
| Virtual LAN features |
Voice VLAN |
| VLAN support |
Yes |
Data transmission
| Forwarding rate |
171 Mpps Mpps |
| Jumbo frames support |
Yes |
| MAC address table |
32000 entries entries |
| Packet buffer memory |
2 MB MB |
| Static route |
Yes |
| Switching capacity |
230 Gbit/s Gbit/s |
| Throughput |
115 Gbit/s Gbit/s |
Security
| DHCP features |
DHCP guarding, DHCP relay, DHCP server, DHCP snooping |
| IGMP snooping |
Yes |
| Loop protection |
Yes |
Multicast features
Design
| Display type |
LCM |
| Form factor |
1U |
| Housing material |
SGCC |
| LED indicators |
Link, Speed, Status |
| Product colour |
Grey |
| Rack mounting |
Yes |
| Reset button |
Yes |
| Stackable |
Yes |
Power
| AC input frequency |
50/60 Hz Hz |
| AC input voltage |
100 – 240 V V |
| Power consumption (max) |
60 W W |
| Power source |
AC/DC/PoE |
| Power supply included |
Yes |
| Redundant power supply (RPS) support |
Yes |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) power per port |
15.4 W W |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
24 |
| Total Power over Ethernet (PoE) budget |
600 W W |
Operational conditions
| Operating relative humidity (H-H) |
10 – 90% % |
| Operating temperature (T-T) |
-5 – 40 °C °C |
Weight & dimensions
| Depth |
400 mm mm |
| Height |
44 mm mm |
| Weight |
6.2 kg g |
| Width |
442.4 mm mm |
