What This Product Does
juhtmevaba N PCI Express 2.0(x1) Adapter TL-WN881ND allows you to connect a desktop computer to a juhtmevaba network and access high-speed Internet connection. Comply with IEEE 802.11n, they provide juhtmevaba speed up to 300Mbps, which is beneficial for the online gaming or even HD video streaming.
juhtmevaba N – Speed & Range
MIMO (multiple input, multiple output antennas) technology, it shows more excellent abilities of mitigating data loss over long distances and through obstacles in a small office or a large apartment, even in a steel-and-concrete building. Above all, you could easily pick up the juhtmevaba network during long-distance connection where legacy 11g products may not!
CCA Technology – Stable juhtmevaba Signals
Clear Channel Assessment (CCA) automatically avoids channel conflicts using its clear channel selection feature and fully realizes the advantages of channel binding, greatly enhanced the juhtmevaba performance.
WPA / WPA2 Encryptions
WPA/WPA2 encryption standards ensure your juhtmevaba connection is safe from intruders.
Easy Setup
Either using the optimized user liides and setup wizard or the CD (kaasas) setup wizard will allow you to get ‘online’ quickly and easily.
- juhtmevaba N speed up to 300Mbps makes it ideal for video streaming, online gaming and Internet calls*
- MIMO technology with stronger signal penetration strength, wider juhtmevaba coverage, providing better performance and stability
- Easily setup a highly secured juhtmevaba link with WPS™ (Wi-Fi Protected Setup)
Tehnilised andmed
Üldine
| Tootja |
Tp-Link |
| Mudel |
TL-WN881ND |
Ports & interfaces
| Connectivity Technology |
juhtmevaba |
| Host Liides |
PCI Express |
| Liides |
WLAN |
Network
| Sagedus Range |
2.4 – 2.4835 GHz GHz |
| Maximum Data Transfer Rate |
300 Mbit/s Mbit/s |
| Modulation |
16-QAM, 64-QAM, DBPSK, DQPSK, OFDM |
| Networking Standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security Algorithms |
64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK, WPS |
| Top Wi-Fi Standard |
Wi-Fi 4 (802.11n) |
| Wi-Fi |
jah |
| Wi-Fi Band |
Single-band (2.4 GHz) |
| Wi-Fi Standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wlan Data Transfer Rates Supported |
11,54,150,300 Mbit/s Mbit/s |
Design
| Antenna |
jah |
| Antenna Pistik Type |
RP-SMA |
| Antenna Design |
External |
| Antenna Direction Type |
Omni-directional |
| Antenna Gain Level (Max) |
2 dBi dBi |
| Component For |
PC |
| Internal |
jah |
| Led Indicators |
jah |
| Operating Modes |
Infrastructure mode |
| Product Värv |
Green |
System requirements
| Linux Operating Systems Supported |
jah |
Operational conditions
| Operating Relative Humidity (H-H) |
10 – 90% % |
| Operating Temperature (T-T) |
0 – 40 °C °C |
| Salvestusmaht Relative Humidity (H-H) |
5 – 90% % |
| Salvestusmaht Temperature (T-T) |
-40 – 70 °C °C |
Weight & dimensions
| Sügavus |
51 mm mm |
| Kõrgus |
3.3 mm mm |
| Laius |
59.7 mm mm |
Technical details
| Compliance Certificates |
RoHS, Federal Communications Commission (FCC), CE |
