TP-LINK TL-SG105E on kompaktne 5-pordiline Gigabit juhtitud võrgumuundur, mis sobib ideaalselt väikeste kontorite ja koduste võrkude laiendamiseks. Seade tagab kiire ja usaldusväärse andmesidevõrgustiku rajamise ja haldamise.
Muundur toetab täielikku Gigabit-kiirust (10/100/1000 Mbps) kõigil portidel, võimaldades kiireid andmeedastusi. Integreeritud Smart Management funktsioon pakub Web-põhist haldusliidest, kus saab konfigureerida pordi peeglerdamist ja QoS-i eelistusi vastavalt teie vajadustele.
Kompaktne must disain sobib ideaalselt erinevate keskkondadega. Seade kasutab alalisvoolu toiteallikat ja on väga energiatõhus. Paigaldamine on lihtne – lihtsalt ühendage kaablid ja seade töötab otsekohe.
- Portide arv: 5 x RJ-45 Gigabit Ethernet
- Lülitamise kiirus: 10 Gbit/s
- Edastuskiirus: 7,44 Mpps
- Haldus: Web-põhine haldusliiides
- QoS tugi: Jah
- Port Mirroring: Jah
- Kiht: Layer 2 (L2)
- Värvus: Must
- Mõõtmed: 100 x 98 x 25 mm
- Toiteallikas: DC (kaasas)
Tehnilised andmed
Üldine
| Tootja |
Tp-Link |
| Mudel |
TL-SG105E |
Management features
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2 |
| Switch type |
Managed |
| Web-based management |
Yes |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
5 |
Network
| 10G support |
No |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T |
| Link aggregation |
Yes |
| Networking standards |
IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Number of VLANs |
32 |
| Port mirroring |
Yes |
| Virtual LAN features |
Port-based VLAN |
| VLAN support |
Yes |
Data transmission
| Forwarding rate |
7.44 Mpps Mpps |
| Jumbo frames |
16000 |
| Jumbo frames support |
Yes |
| MAC address table |
2000 entries entries |
| Packet buffer memory |
1 MB MB |
| Store-and-forward |
Yes |
| Switching capacity |
10 Gbit/s Gbit/s |
Security
Design
| LED indicators |
Yes |
| Product colour |
Black |
Performance
| Compatible operating systems |
Microsoft Windows XP, Vista Windows 7, Windows 8, MAC OS, NetWare, UNIX / Linux |
Power
| Input current |
0.6 A A |
| Input voltage |
5 V V |
| Power consumption (max) |
2.82 W W |
| Power source |
DC |
| Power supply included |
Yes |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
No |
Operational conditions
| Heat dissipation |
9.07 BTU/h BTU/h |
| Operating relative humidity (H-H) |
10 – 90% % |
| Operating temperature (T-T) |
0 – 40 °C °C |
| Storage relative humidity (H-H) |
5 – 90% % |
| Storage temperature (T-T) |
-40 – 70 °C °C |
Weight & dimensions
| Depth |
98 mm mm |
| Height |
25 mm mm |
| Width |
100 mm mm |
