Gigabyte P450B on usaldusväärselt toiteplokk, mis on mõeldud keskmise võimsusega arvutitele. 450-vatine võimsus ja 80 PLUS Bronze sertifikaatidega efektiivne energiatarbmine muudavad selle suurepäraseks valikuks tasakaalustatud jõudlus-hinna suhte otsijatele.
Plokk kasutab 120 mm ventilaatori jahutussüsteemi, mis tagab stabiilse temperatuuri ja madalat mürataoset igapäevase kasutamise ajal. ATX standard-kujundus tagab ühilduvuse enamus arvutikastidega.
- Võimsus: 450 W
- Kasutegur: 85%
- Sertifikaadid: 80 PLUS Bronze
- Sisendpinge: 100–240 V
- Formaat: ATX
- Jahutus: 120 mm ventilaator
- Mudel: GP-P450B
Tehnilised andmed
Üldine
| Tootja | Gigabyte |
|---|---|
| Mudel | P450B |
Power
| AC input frequency | 50 – 60 Hz Hz |
|---|---|
| AC input voltage | 100 – 240 V V |
| Combined power (+12V) | 432 W W |
| Combined power (+3.3V) | 103 W W |
| Combined power (+5V) | 103 W W |
| Combined power (+5Vsb) | 15 W W |
| Combined power (-12V) | 3.6 W W |
| Efficiency | 85% % |
| Hold time | 16 ms ms |
| Input current | 8 – 4 A A |
| Max output current (+12V) | 36 A A |
| Max output current (+3.3V) | 18 A A |
| Max output current (+5V) | 15 A A |
| Max output current (+5Vsb) | 3 A A |
| Max output current (-12V) | 0.3 A A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Total power | 450 W W |
Ports & interfaces
| ATX power connector (20+4 pin) | Yes |
|---|---|
| Cabling type | Non-Modular |
| CPU power cable length | 60 cm mm |
| CPU power connector (4+4 pin) | Yes |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| Motherboard power cable length | 55 cm mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express connector | Yes |
| PCI Express power cable length | 55 cm mm |
| PCI Express power connectors (6+2 pin) | 2 |
| Peripheral (Molex) power cable length | 500 mm mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| SATA power cable length | 500 mm mm |
Performance
| 80 PLUS certification | 80 PLUS Bronze |
|---|---|
| ATX version | 2.31 |
| Bearing technology | HDB |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
Design
| Cooling type | Active |
|---|---|
| Fan diameter | 12 cm mm |
| Fan location | Top |
| Number of fans | 1 fan(s) fan(s) |
| On/off switch | Yes |
| Product colour | Black |
Weight & dimensions
| Depth | 140 mm mm |
|---|---|
| Height | 86 mm mm |
| Width | 150 mm mm |
